Battery Testing Chambers

Battery Testing Options to Meet Your Needs

ATPPRIME

ATPPRIME logo

ATP an all-inclusive test system fits with new or existing battery cyclers. Available for pouch, prismatic, coin, cylindrical, and pack cells

ATPFLEX

ATPFLEX logo

Flexible battery test fixtures for your existing test chamber choose the quantity, type, and connector for easy mix or swap and test.  Available for pouch, prismatic, coin, cylindrical, and pack cells

Battery-Testing-Chamber-Clip
ATPPRIME

Drastically Change the Way You Test Batteries

ATPPRIME makes your battery testing easy to set-up and modify for different types of cells and testing.  The universal connectors are available in Kelvin clips and power pole for quick insertion, removal, and switching between cell types.  You can test virtually any cell type: coin, cylindrical, prismatic, pouch, and pack cells.Patent-Pending-2020



ATPFLEX-VIDEO
ATPFLEX

Battery Testing Flexibility for Your Existing Test Chamber

  • Safely test multiple configurations within two to six channels
  • Effectively organize cables
  • Securely connect your battery cells to your battery cycler
  • Custom-engineered epoxy laminate for a non-conductive surface and even air-flow
    Patent-Pending-2020



Checkmark icon

Test Multiple Cell Types with the Same Fixture


With ATP Battery Testing, you can easily change from one style holder to another or support multiple styles within one chamber.

ATPPRIME is a self-contained fixture that holds 48 cells organized over four shelves that fit into an environmental test chamber specially designed to maximize airflow and constant temperature conditions.

Checkmark icon

Easy Access


Because everything is preset and permanently wired, ATPPRIME drastically reduces the time required to set-up test environments. The fixture features four sliding shelves that fully-extend at least two inches beyond the enclosed workspace. The easy-access sliding shelves, keep you safe from exposure to high heat and dangerous chemicals.

Wiring remains safe as shelves move in and out as they easily extend and retract through an IGUS track allowing connections to remain intact.

Checkmark icon

Accurate Readings


ATPPRIME fixtures have integrated Battery Interface Boards (BIB) to ensure that precise, strong charge and discharge data signals are transmitted from each cell to your battery cycler.

Every battery cell connects to a clearly labeled channel, and the labeling continues through wiring and to the battery cycler, making it next to impossible to make an error in data collection. With the IGUS track and consistent labeling, you can say good-bye to spaghetti cable headaches.

Checkmark icon

Specialized Test Surface


A custom engineered epoxy shelf ensures a flat surface, distributed airflow, and optimum configuration to minimize events or complete failure. The mix of materials used and the cell configuration often eliminates or significantly reduces propagation during an event.

Battery testing pack connector made by Associated Environmental Systems

Pack

Battery testing coin cell connector made by Associated Environmental Systems.

Coin Cell

Battery testing coin cell connector made by Associated Environmental Systems.

Cylindrical

Battery testing coin cell connector made by Associated Environmental Systems.

High Current

Battery testing coin cell connector made by Associated Environmental Systems.

Prismatic Cell/Pouch

The Full Solution

From your batteries to cell holders to fixtures and wiring to your specific battery cycler, AES will be with you every step of the way, including set-up and testing every cell connection to ensure success.

Request A Quote

Get a Fully Equipped ATP For Optimized Battery Testing

Carefully selected materials and configuration are unique and patent pending.  The system allows for more batteries under test while maintaining safety and increased uniformity.

Batter Testing Safety Features

Multi-sensing gas detectiongas-detection
Interchangeable gas cartridges sense
SO₂, SO₄,H₂,O₂,CO



Over-pressure ventpressure-vent
Charcoal burst disk & pressure release valve
vents with constant positive pressure draw
Nitrogen Purgepurge
Creates an inert environmental inside chamber

Inert gas pressure ventpressure-vent
Quickly removes unwanted gases

Dry air purgedry-air
Quickly adds oxygen inside chamber and removes humidity

Ventilation blowervent-blower
Quickly adds clean air

Alerts alerts
Controller has additional temperature measure rate of change visual & sound warnings at chamber & remotely through AESONE Console
  • Spark resistant & containment features
    Stainless steel workspace
    •Limited-temperature internal sheath heaters with external electrical connections
    •Circulation, aluminum fan blade/blower wheel
  • •Internal light safety sealed
  • •Heavy-duty door latch & hinges
    •Electromagnetic deadbolt secure lock
    •Solenoid door interlock
    •Reinforced door blank


EUCAR - European Council for Automotive R&D

Severity Level Description Effects
0 No effect No effect. No loss of functionality
1 Reversible Loss of Function No defect; no leakage; no venting; fire, or flame; no rupture; no explosion; no exothermic reaction or thermal runaway.  Cell reversibility damaged. Repair of protection device needed
2 Irreversible Defect/Damage No leakage; no venting, fire, or flame; no rupture; no explosion; no exothermic reaction or thermal runaway. Cell irreversibly damaged. Repair needed
3 Leakage Δ mass <50%

No venting, fire, or flame*; no rupture; no explosion. Weight loss <50% of electrolyte weight (electrolyte = solvent + salt)

4 Venting Δ mass >=50% No fire or flame*; no rupture; no explosion. Weight loss ≥50% of electrolyte weight (electrolyte = solvent + salt)
5 Fire or Flame No rupture; no explosion (i.e., no flying parts)
6 Rupture No explosion, but flying parts of the active mass
7 Explosion Explosion (i.e., disintegration of the cell)



Battery Testing Standards

Standard Application
IEC 60086-4: Primary Batteries, Safety of Lithium Batteries
IEC 61960: Secondary Lithium Cells and Batteries for portable applications
IEC 62133: Secondary Cells & Batteries Containing Alkaline or Other Non-Acid Electrolytes – Safety Requirements for Portable Sealed Secondary Cells, & for Batteries Made from them, for Use in Portable Applications
IEC 62281: Safety of Primary and Secondary Lithium Cells and Batteries during Transport
IEC 62660-2: Reliability & Abuse Testing for Lithium-Ion Cells in Electric Vehicles
RTCA DO-311: Minimum Operational Performance Standards for Rechargeable Lithium Battery Systems
SAE J2464: EV & HEV Rechargeable Energy Storage System Safety & Abuse Testing
SAE J2929: Safety Standard for Electric and Hybrid Vehicle Propulsion Battery Systems Utilizing Lithium-Based Rechargeable Cells
UL 1642: Standard for Lithium Batteries
UL 2580: Batteries for use in Electric Vehicles
UN/DOT 38.3: UN Lithium Battery Testing Requirements



XCHANGE Dashboard
Collect all your data in one place with AESONE CONNECT
Technician switching out battery
Easily switch out 48 battery cell holders in less than 5 minutes
Diagram of cable management
Cable management system that collects, organizes, and tucks all the wires and cables under each shelf
